Nvidia EMAXX-MCP61D3-iCafe User Manual

- 28 -
nVIDIA MCP61 Series User's Manual
• Resume On PCIE Wake#
Disable/Enable PCIE PME to generate a wake event.
• Resume On LAN(MAC)
Disable/Enable LAN(MAC) to generate a wake event.
• Resume On Ring
Disable/Enable RI to generate a wake event.
• Resume On USB
options:Disabled,Enabled
• Resume By RTC Alarm
When set to [Enabled], you can set the date and time you would like the Soft-Off PC to
power-on in the “RTC Alarm Date (Days)” and “System Time” items. However, if the system is
being accessed by incoming calls or the network (Resume On Ring/LAN) prior to the date and
time set in these items, the system will give priority to the incoming calls or network instead.
• PWRON After PWR-Fail
This item selects the system action after an AC power failure.
[Off]: When power returns after an AC power failure, the system’s power remains off.
You must press the Power button to power-on the system.
[On]: When power returns after an AC power failure, the system’s power will be powered on
automatically.
[Former-Sts]: When power returns after an AC power failure, the system will return to the
state where you left off before power failure occurred. If the system’s power
is off when AC power failure occurs, it will remain off when power returns. If
the system’s power is on when AC power failure occurs, the system will
power-on when power returns.
• Keyboard WakeUp
Any key:Support "On/OFF" and "Suspend" for Power Button Mode.
• Specic Key for PowerOn
When the Power On function is set to Password, use this item to set the password.
• Mouse WakeUp
Optional:Disabled,Enabled.
・
Press <Esc> key to return to "Power" menu.
►
PC Health
Click <Enter> key to enter its submenu, it will be display hardware health conguration,
including System temperature, CPU temperature, FAN speed and all kinds of voltages.
BIOS SETUP UTILITY
Power
PC Health Fan configuration
mode setting
←
Select Screen
↑↓
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
System Temperature
CPU Temperature
NB Temperature
Vcore
+3.3V
Dram Voltage
NB Voltage
SB Voltage
+5V
VBAT
:23
o
C/73
o
F
:53
o
C/127
o
F
:57
o
C/134
o
F
:1.232 V
:3.232 V
:1.504 V
:1.168 V
:1.248 V
:4.992 V
:3.248 V
CPUFAN Mode Setting
CPUFAN PWM Control
[Manual Mode ]
[250]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
