Nvidia EMAXX-MCP61D3-iCafe User Manual

- 21 -
nVIDIA MCP61 Series User's Manual
►
Chipset
Click <Enter> key to enter its submenu.
BIOS SETUP UTILITY
Advanced
Advanced Chipset Setting Options
PCI Express->PCI->
IGP->PCI->PCI Expr
←
Select Screen
↑↓
Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
WARNING: Setting wrong values in below sections
may cause system to malfunction.
NUMM ROM Version: 4.082.10
Primary Graphics Adapter [PCI Express->PCI]
OnChip and PCIe VGA selection [Disable Onchip ]
iGPU Frame Buffer Detect [Disable]
OnChip VGA Frame Buffer Size [64MB]
IDE Configuration
Onboard IDE Controller
Serial-ATA 0
Hard Disk Write Protect
IDE Detect Time Out(Sec)
ATA(PI) 80Pin Cable Detection
RAID Setup
nVidia RAID Function
[Enable]
[Enable]
[Disable]
[35]
[Host]
[Disabled]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
Options
• Primary Graphics Adapter
Options:PCI Express ->PCI->IGP,IGP->PCI->PCI Express
• OnChip and PCIe VGA selection
Select OnChip or PCIe VGA to diaplay
• iGPU Frame Buffer Detect
iGPU Frame Buffer Size Auto Detect
• OnChip VGA Frame Buffer Size
iGPU Frame Buffer size.
• Onboard IDE Controller
Allows BIOS to Enable or Disable IDE Controller
• Serial-ATA 0
Options:Enabled,Disabled.
• Hard disk write protect
Disable/enable device write protection.this will be efctive only if device is accessed through
BIOS
• IDE Detect Time Out
Select the time out value for detecting ATA/ATAPI device(s)
• ATA(PI) 80Pin Cable Detection
Select the mechanism for detecting 88pin ATA(PI) Cable.
• nVidia RAID Function
Options:Enabled,Disabled.
