- 24 -
nVIDIA MCP61 Series User's Manual
• Clear NVRAM
This item for clearing NVRAM during system boot.
Optional:Yes,No
• Plug & Play O/S
This item lets the BIOS congure all the devices in the system or lets the operating system
congure plug and play (PnP) devices not required for boot if your system has a Plug and Play
operating system.
Optional:Yes,No
• PCI Latency Timer
This item sets value in units of PCI clocks for PCI device latency timer register.
Optional:32,64,96,128,160,192,224,248
• Allocate IRQ to PCI VGA
This item assigns IRQ to PCI VGA card if card requests IRQ or doesn't assign IRQ to PCI VGA
card even if card requests an IRQ.
Optional:Yes,No
• Palette Snooping
This item informs the PCI devices that an ISA graphics device is installed in the system so the
card will function correctly.
Optional:Disabled,Enabled
• PCI IDE BusMaster
This item uses PCI busmastering for BIOS reading / writing to IDE derives.
Optional:Disabled,Enabled
BIOS SETUP UTILITY
Advanced
Advanced PCI/PnP Settings Clear NVRAM during
System Boot.
←
Select Screen
↑↓
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
WARNING: Setting wrong values in below sections
may cause system to malfunction.
Clear NVRAM
Plug & Play O/S
PCI Latency Timer
Allocate IRQ to PCI VGA
Palette Snooping
PCI IDE BusMaster
OffBoard PCI/ISA IDE Card
IRQ3
IRQ4
IRQ5
IRQ7
IRQ9
IRQ10
IRQ11
IRQ14
IRQ15
DMA Channel 0
DMA Channel 1
DMA Channel 3
DMA Channel 5
DMA Channel 6
DMA Channel 7
Reserved Memory Size
Engineer mode
[No]
[No]
[64]
[Yes]
[Disabled]
[Enabled]
[Auto]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Available]
[Disabled]
[Disabled]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
