Nvidia EMAXX-MCP61D3-iCafe User Manual

- 31 -
nVIDIA MCP61 Series User's Manual
►
AMD Overclocking Conguration
Click <Enter> key to enter its submenu.
BIOS SETUP UTILITY
JUSTw00T!
AMD Overclocking Configuration
Configure CPU
frequency and
voltage
←
Select Screen
↑↓
Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
Speed:2727MHZ, NB Clk:2000MHZ
Maximum FSB Multiplier :13.5x
Processor Frequency Multiplier [Auto]
Processor Voltage [Auto]
Processor NB Frequency(NBFID) [Auto]
Processor NB Voltage(NBVID) [Auto]
SB to K8(CPU) Freq Auto [Enabled]
SB to K8(CPU) LinkWidth [16
↓ 16↑
]
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
• Processor Frequency Multiplier
options:Auto,X4.0 800 MHZ,X4.5 900MHZ,X5.0 1000MHZ,X5.5 1100MHZ,X6.0 1200MHZ,X6.5
1300MHZ, X7.0 1400MHZ ,X7.5 1500MHZ
• Processor Voltage
Options:Auto,1.425V,1.412V,1.400V,1.387V,1.375V,1.362V,1.350V,1.337V
• Processor NB Frequency (NBFID)
Options:Auto,X4 800MHZ,X5 1000MHZ,X6 1200MHZ,X7 1400MHZ,X8 1600MHZ,X9 1800MHZ,
X10 2000MHZ,X11 2200MHZ.
• Processor NB Voltage(NBVID)
Options:Auto,1.425V,1.412V,1.400V,1.387V,1.375V,1.362V,1.350V,1.337V
• SB to K8(CPU) Freq Auto
SB to K8(CPU) frequency selection by CPU capability.
• SB to K8(CPU)LinkWidth
SB to K8(CPU) LinkWidth selection
・
Press <Esc> key to return to "JUSTw00T!" menu.
