HARDWARE INSTALLATION
3 Remove any existing graphics card (if there is one). Save hardware
(such as screws and brackets) to use when installing the NVIDIA
graphics card.
!
Attention: If your system has been running for a period of
time prior to opening the panels, it is very important that you
wait until the graphics card in your system has cooled before
taking the card out of the system. Graphics cards get very hot
when they have been operating for any length of time.
4 Remove two adjacent slot covers if you do not have a graphics card
installed.
Note: The GeForce GTX 970 card is double-wide so it will require
removing two slot covers.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nvidia GeForce GTX 970 and is the answer not in the manual?

Nvidia GeForce GTX 970 Specifications

General IconGeneral
ArchitectureMaxwell
CUDA Cores1664
Base Clock1050 MHz
Boost Clock1178 MHz
Memory4 GB GDDR5
Memory Interface256-bit
Memory Bandwidth224 GB/s
TDP145 W
GPUGM204
DirectX Support12
OpenGL Support4.5
Shader Model5.0
Maximum Digital Resolution5120x3200
Maximum Display Outputs4
HDCP SupportYes
Recommended Power Supply500 W
Outputs1 x HDMI, 1 x DisplayPort, 2 x DVI
PCI Express InterfacePCIe 3.0 x16
SLI SupportYes
Power Connectors1 x 6-pin, 1 x 8-pin
