TABLE OF CONTENTS
TABLE OF CONTENTS
Introduction 1
About This Guide 1
Minimum System Requirements 2
Unpacking 3
Equipment 3
Hardware Installation 5
Safety Instructions 5
Before You Begin 6
Installing the GeForce Graphics Card 6
Software Installation 11
GeFore Experience Software Installation 11
Driver Installation 13
Configuring SLI 15
Accessing NVIDIA Control Panel 15
Enabling/Disabling SLI 16
Configuring HDMI 17
Enabling Audio Over HDMI 17
Features 19
Compliances 23

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nvidia GeForce GTX 970 and is the answer not in the manual?

Nvidia GeForce GTX 970 Specifications

General IconGeneral
ArchitectureMaxwell
CUDA Cores1664
Base Clock1050 MHz
Boost Clock1178 MHz
Memory4 GB GDDR5
Memory Interface256-bit
Memory Bandwidth224 GB/s
TDP145 W
GPUGM204
DirectX Support12
OpenGL Support4.5
Shader Model5.0
Maximum Digital Resolution5120x3200
Maximum Display Outputs4
HDCP SupportYes
Recommended Power Supply500 W
Outputs1 x HDMI, 1 x DisplayPort, 2 x DVI
PCI Express InterfacePCIe 3.0 x16
SLI SupportYes
Power Connectors1 x 6-pin, 1 x 8-pin
