Nvidia JETSON TX1 Quick Start Guides

CONNECTION SYSTEM LAYOUT
DC Power [2]
[15] Expansion
Header
[13] Expansion
Header Voltage
Selection
Antennas [3]
[17] UART
[12] Secondary
Expansion
Micro USB [4]
[19] Power Button
(Power BTN)
[18] JTAG
[16] Fan Power
USB Type A [5]
[20] Force Recovery
Button (REC)
HDMI [7]
[21] User Defined
Button (Vol)
SD Card [8]
[22] Reset Button
(RST)
10/100/1000 [9]
Ethernet
[14] Camera Module
* Only included in
certain SKUs
PCI-E x4 [10]
[11] Display
M.2 E [6]
Jetson TX1 [1]
[23] SATA Data and
Power

Nvidia JETSON TX1 Specifications

General

Brand	Nvidia
Model	JETSON TX1
Category	Microcontrollers
Language	English
