Nvidia Quadro M6000 Sync

NVIDIA Quadro M6000 Sync User Guide 4
NVIDIA Quadro M6000 Specifications and Features
 GPU: NVIDIA Quadro M6000
 Maximum core clock: 988 MHz
 CUDA cores: 3072
 GPU memory: 12GB GDDR5
 Memory clock: 3300MHz
 Memory interface: 384-bit
 Memory bandwidth: 317 GB/s
 GPU memory: 12 GB GDDR5
 PCI Express: PCIe Gen 3.0 x16
 Auxiliary power: 8-pin connector
 Maximum power consumption: 250 W
 Physical dimensions: 4.376 x 10.5 inches, dual slot
Display Connectors
 One Dual-Link DVI-I connector
 Four Display Port 1.2 connectors
 Stereo connector (via supplied stereo connector bracket)
Internal Connectors and Headers
 8-pin auxiliary power connector
 Sync connector
 SLI connector
 Stereo header
Display Support
 Maximum VGA resolution: 2048 x 1536 x 32 bpp at 85Hz
 Maximum DVI Dual Link resolution: 2560 x 1600 x 32 bpp at 60Hz
 Maximum Display Port 1.2 resolution: 4096 x 2160 x 36 bpp at 60Hz
 High-bandwidth digital content protection (HDCP) support
NVIDIA Quadro Sync Specifications and Features
Quadro Sync Board
 Six layer printed circuit board (PCB)
 Physical dimensions: 6.15” inches x 4.37” inches
 Power: 6-pin PCI or SATA power connector
 Maximum power consumption: 12 W
Connectors and Status Indicators
 4 SLI-style edge fingers for connection to compatible GPUs
 BNC house sync
 RJ45 1
st
Frame Lock sync (using CAT5 straight-through cable)
 RJ45 2
nd
Frame Lock sync (using CAT5 straight-through cable)
 Frame Lock and Stereo Sync Status LEDs
