Tesla K10 GPU Accelerator BD-06280-001_v05 | 4
MECHANICAL SPECIFICATIONS
PCI EXPRESS SYSTEM
The Tesla K10 boards (Figure 2) conform to the PCI Express full height (4.376 inches by
10.5 inches) form factor. Figure 2 is shown without the bracket.
Figure 2. Tesla K10 GPU Accelerator
Note: The final product will ship with an 8 and 6-pin connector and shroud.
10.5 inches
4.376 inches
