SPECIFICATIONS
N-Series subwoofers incorporate
features designed to optimize
performance, durability and
usability in a real automotive
environment, including:
•
Ultra-Light Non Pressed Paper Cone
Stiff and lightweight material allows
the subwoofer to remain accurate and
responsive even at high volume levels.
•
Custom Blended Foam Surround
High-roll design allows for extreme
excursion possible.
•
2” High Temperature Aluminum
Voice Coil
Provides robust power handling capabilities
and excellent heat dissipation.
•
High Strength Steel Basket
Retains exceptional rigidity to minimize distortion.
•
Chrome-Plated, Spring-Loaded
Push Terminals
Simple and secure installation.
Visit: nvx.com | Call: 213.444.1689 | 15303 Ventura Blvd. 9th Floor, Sherman Oaks, CA 91403
2
Varies based on enclosure type and volume. See pages 4 and 5.
A
B
D
C
N-SERIES NSW102V2 NSW104V2 NSW122V2 NSW124V2
Power Range (RMS)
200-350 W 200-350 W 200 - 350 W 200 - 350 W
Impedance per Voice Coil
2 Ohms 4 Ohms 2 Ohms 4 Ohms
Frequency Response
20-200 Hz 20-200 Hz 20 - 200 Hz 20 - 200 Hz
Xmax
10.78 mm 10.78 mm 12 mm 12 mm
Fs
36.40 35.40 28.50 28
Vas
17.3 2 19.69 54.73 56.29
Sd
31.41 31.41 51.87 51.87
Qts
0.791 0.706 0.751 0.734
SPL (1W/M)
89 89 92 92
Net Weight
7.20 lbs (3.26 kg) 7.20 lbs (3.26 kg) 8.57 lbs (3.88 kg) 8.57 lbs (3.88 kg)
A Overall Diameter
10.28” (261 mm)
12.40” (315 mm)
B Mounting Diameter
9.65” (245.11 mm)
11.69” (297 mm)
C Cutout Diameter
9.06” (230.12 mm)
10.83” (275.08 mm)
D Mounting Depth
4.20” (106.68 mm) 5.01” (127.25 mm)
NSW102V2 / 104V2 | NSW122V2 / 124V2
