SMW10D4 | SMW12D4
S-Series subwoofers incorporate
features designed to optimize
performance, durability, and
usability in a real automotive
environment, including:
• Ultra-Light & Durable Polypropylene Cone With a
Reinforced Carbon Fiber Dust Cap
Sti and lightweight material allows the subwoofer
to remain accurate and responsive even at high volume levels.
• A Versatile Shallow Mounting Depth Design
The S-Series woofers are NVX’s rst-ever true shallow mount
subwoofers. These subwoofers allow you to install them in a
much smaller box that will take up far less space in your trunk
or hatch.
• Up to a 2.5” High-Temperature Aluminum Voice Coil
The 2” or 2.5” voice coil provides robust power handling
capabilities and excellent heat dissipation.
• Chrome-Plated, Spring-Loaded Push Terminals
Simple and secure installation.
2
S-SERIES SMW10D4 SMW12D4
Power range (RMS) 350 W 400 W
Voice coil(s) Dual Dual
Voice coil diameter 2” 2.5”
Impedence per voice coil 4 Ohm 4 Ohm
Frequency response 25 - 350 Hz 25 - 350 Hz
Xmax 8 mm 8 mm
Fs 35.83 Hz 29.1 Hz
Vas 34.71 L 64.86 L
Sd 53.6 in
2
/ 0.0346 m
2
79.2 in
2
/ 0.0511 m
2
Qts 0.5525 0.5734
Qes 0.6216 0.6448
SPL (2.83V/1M) 88 dB 88 dB
Re 6.4 Ohm 6.4 Ohm
Qms 4.9677 5.1827
Net weight 8.4 lb 11 lb
SPECIFICATIONS
A Overall Diameter
10.125” 12.3125”
B Mounting Diameter
9.75” 11.75”
C Cutout Diameter
9.25” 11.375”
D Mounting Depth
3.25” 3.9375”
Varies based on enclosure type and volume. See page 3.
Visit: nvx.com | Call: 502.200.8010 | 10645 Freeport Dr, Louisville, KY 40258
A
B
D
C
