10
SEARCH
SPEED
0-3 1 Search speed setting.o:slow;3:fast
PWL 0-15 15 White peak limit
OSD
CONTRAST
0-3 0 OSD contrast setting.0:bitght;3:dark
BLUE STR. ON/OFF ON Blue level stretch option
BSD ON/OFF ON Black level stretch range.ON:30 IRE;OFF:20IRE.
AAS ON/OFF ON Black level actived area.ON:no more than 10%of black
background;OFF:no more than 20% of black background.
CORING 0-3 0 Coring and decrease nosie.0:off.
M7 AGC-TOP 0-63 24 RF AGC adjusting
AGC-SPEED 0-3 1 AGC delay time adjusting
LOGO OPT ON/OFF OFF LOGO option
VOL6 0-63 17 Volume setting of 10%
VOL16 0-63 32 Volume setting of 25%
VOL32 0-63 48 Volume setting of 50%
VOL63 0-63 63 Volume setting of 100%
7KEYS ON/OFF OFF “POWER”key option of key board
X RAY ON/OFF OFF X RAY protect function option
OSVE ON/OFF OFF AKB detect line hide option(supported by TDA9353/63)
HCO ON/OFF OFF Auto horizenal range revise option(supported by TDA9353/63)
M8 FREQUENCY 50HZ 60HZ Display vertical frequency automaticly
VSLOPE 0~63 31 31 Vertical slope adjusting
VSHIFT 0~63 31 31 Vertical shift adjusting
VAMP 0~63 31 31 Vertical size adjusting
VSCOR 0~63 31 31 Vertical correct adjusting
HSHIFT 0~63 31 31 Horizontal shift adjusting
RGBHS 0~63 31 Vertical shift adjusting of RBG/YUV
RGB HPOS 0~63 31 OSD horizontal shift adjusting of RBG/YUV
EW WIDTH 0~63 31 Horizontal range adjusting
EW PARA 0~63 31 East-west curve adjusting
UP CORNER 0~63 31 Up conner adjusting
LO CORNER 0~63 31 Low conner adjusting
H-PARA 0~63 31 Paralleloqram adjusting
H-BOW 0~63 31 Bow adjusting
EW-TRAPE 0~63 31
Trapezoid adjusting
M9 BT 0~63 48 Brightness adjusting of white balance
CT 0~63 48 Contrast adjusting of white balance
SC OFF Single horizontal line.open by “V+”;closed by “V-”
RB 0~63 32 Red cut adjusting
GB 0~63 32 Green cut adjusting
