NXP Semiconductors TDA9351 SERIES - Page 11

11
RD 0~63 32 Red drive adjusting
GD 0~63 32 Green drive adjusting
BD 0~63 32 Blue drive adjusting
SB 0~63 40 Sub-brightness adjusting
ATTACHED TABLE1
BAND=0 BAND=1 BAND=2
PIN10(B2) PIN11(B1) PIN10(B2) PIN11(B1) PIN10(B2) PIN11(B1)
VL 0 0 0 1 1 0
VH 1 0 1 0 0 1
U 0 1 1 1 1 1
TABLE2
AV OPTION:MENU1→AV CFG;
O=TV→AV;1=TV→AV1→AV2;2=TV→AV1→AV2→S-VIDEO;3=TV→AV1→AV2→S-VIDEO→YUV;
5= TV→AV→S-VIDEO;6= TV→AV→S-VIDEO→YUV;7= TV→AV→YUV;8=TV→EURO;
9=TV→AV→EURO
When“AV OPT”is setting “OFF”,the logic table of AV control
MODE TV AV2 AV/AV1/YUV/EURO(RGB) SVHS
Pin62 L L H H
Pin63 L H L H
When“AV OPT”is setting “ON”,the logic table of AV control
MODE TV AV2 AV/AV1/YUV/EURO(RGB) SVHS
Pin62 H L L L
Pin63 H H L L
TABLE3
Pin5,pin7,pin8 is variable for c
ompating with other hardware
NTSC Control SAW filter ,switch between M
and N
VOL2 PWM control output for left AMP.
DVD Output for DVD&TV cabine control VOL1 PWM control output for right AMP.
SCART Scart detect level input WOOFER For woofer controlling
MUTE For audio mute mode MUTE2 For mute mode 2
LED For LED controlling SV-DT S-VIDEO detect level input
BAND3 For band3 controlling 5060 Output for 50/60Hz alternate
