12
2． OM8370
B/W BALANCE
MI Items Vari
able
Prese
t
discription
DRI R 0~63 32 RED DRIVE
DRI G 0~63 32 GREEN DRIVE
DRI B 0~63 32 BLUE DRIVE
CUT R 0~63 32 RED CUT
CUT G 0~63 32 GREEN CUT
BT 0~63 32 Brightness adjust of white balance
CT 0~63 32 contrast adjust of white balance
Note: press "MUTE" To enter the single horizontal line mode,and press again exit.
S0 POW 0-2 1 Switch on mode,0:standby,1:power on;2:remember last time.
LOGO ON/OFF OFF LOGO option
DRCS LOAD ON/OFF OFF Speicel letter load for logo(supportted by 24C16,set OFF normally)
SAVER ON/OFF OFF Option of screen saver
MENU BG 0~2 2 Background of menu(0:no;1:blue;2:half tone)
AV control logic level option ON
TV AV1 AV2 SVHS OTHER
PIN62 0 1 0 1 1 OFF
PIN63 0 0 1 1 0
PIN62 1 0 0 0 0
AV OPT ON/OFF
ON
PIN63 1 0 1 0 0
AV2 ON/OFF ON Option of AV2
SVHS ON/OFF OFF Option of SVHS
YUV ON/OFF OFF Option of YUV
SCART ON/OFF OFF Option of SCART
DVD ON/OFF OFF Option of DVD
DVD SRC V/S/YUV V Select of DVD input mode
DVD LOGIC 0-3 3 DVD logic output level select(pin62 63)
S1 FREQUENCY 50HZ Display vertical frequency automaticly
H PH 0~63 31 Horizontal shift adjusting
V SL 0~63 24 Vertical slope adjusting
V SH 0~63 21 Vertical shift adjusting
V SI 0~63 33 Vertical size adjusting
V SC 0~63 27 Vertical correct adjusting
H PH YUV 0~63 31 Horizontal shift adjusting of YUV/RGB
S2 AGC 0~63 24 Adjusting of RF AGC
COOL R 0~63 30 Cool color temperature adjusting of red
COOL G 0~63 32 Cool color temperature adjusting of green
COOL B 0~63 42 Cool color temperature adjusting of blue
WARM R 0~63 42 Warm color temperature adjusting of red
WARM G 0~63 32 Warm color temperature adjusting of green
