13
WARM B 0~63 30 Warm color temperature adjusting of blue
BR-YUV 0~63 32 Bias voltage of red for YUV
BG-YUV 0~63 32 Bias voltage of green for YUV
WIDE 0~63 17 Vertical size adjusting of wide mode
ZOOM 0~63 50 Vertical size adjusting of zoom mode
S3 VP 7~63 38 Vertical shift of OSD
HP 0~63 30 Horizonol shift of OSD
HP-YUV 0~30 30 Horizonol shift of YUV
OSD BRI 0~3 0 Brightness of OSD
S4 AGC-SPEED 0-3 1 AGC delay time adjusting
POW ON TIM 6-15 8 Powe on delay on time setting
VIDEO OUT IF/CVBS CVBS AV out mode option(IF:TV;CVBS:screen)
PIN5 NTSC Compatible with other hardware, see table*
PIN7 VOL1 Compatible with other hardware, see table*
PIN8 MUTE Compatible with other hardware, see table*
AKB ON/OFF ON Auto black level adjusting
NBL ON/OFF OFF Auto detect of black current
RC FORMAT NEC/RC5 NEC Code select of Renote Control
Note:wrong select may cause useless of RC
KEYBOARD SANYO/
PHILIPH
S
SANY
O
Keyboard select
MONO
* For compatible of other hardware, there are different functions of pin 5,7,8.
woofer For woofer control
Vol2 Volume PWM control of right AMP.
Vol1 Volume PWM control of left AMP.
Band3 For band control for the third pin of tuner
NTSC For SAW filter control
SCART Detect signal input of SCART
DVD Output control level for DVD
MUTE Control signal for MUTE
5060 Control signal for 50/60 switch
MUTE2 Control signal for MUTE2
SV-DT Detect signal For S-Video
S5 ENGLISH ON/OFF ON Language option
FRENCE ON/OFF ON Language option
RUSSIAN ON/OFF ON Language option
TURKISH ON/OFF ON Language option
FARSI ON/OFF ON Language option
ARABIC ON/OFF ON Language option
BULGARIAN ON/OFF ON Language option
RUMANNIAM ON/OFF ON Language option
SPANISH ON/OFF ON Language option
