14
PORTUGUESE ON/OFF ON Language option
ITALIAN ON/OFF ON Language option
GERMAN ON/OFF ON Language option
DUTCH ON/OFF ON Language option
SWEDISH ON/OFF ON Language option
NORWEGIAN ON/OFF ON Language option
HUNGARIAN ON/OFF ON Language option
POLISH ON/OFF ON Language option
CZECH ON/OFF ON Language option
SLOVENE ON/OFF ON Language option
CROATIAN ON/OFF ON Language option
MACEDONIAN ON/OFF ON Language option
SERBIAN ON/OFF ON Language option
GREEK ON/OFF ON Language option
Items Variable Preset
S6 UOC VOL SW 0~63 63 Subsidiary contrast setting
UOC/PWM
VOL
0~63 63 Subsidiary color setting
VOL10 0~100 25 Volmule of diagram 25%
VOL25 0~100 50 Volmule of diagram 50%
VOL50 0~100 75 Volmule of diagram 75%
VOL100 0~100 100 Volmule of diagram 100%
WOOFER ON/OFF OFF Woofer option on menu
TDA9860
WOOF
ON/OFF OFF Woofer output mode select (from TDA9860 or PWM)
OFF:PWM;on:TDA9860.
TDA9874
GAIN
ON/OFF OFF Gain of TDA9874 output
AGN ON/OFF OFF Gain of FM output .OFF:normal;no:+6dB
S7 IF 38/38.9/
45.75/
58.75
38.9M IF setting
FMWS 0~2 0 Band width of FM demodulation.0:standard(225kHz) ;1:for FM
over modulation (450kHz);2:over modulation (600kHz)
VST 0~2 0 VST band control option
BAND3
VHFL 0 0
VHFH 1 0
Band
opt=0
UHF 0 1
VHFL 0 1
VHFH 1 0
Band
opt=1
UHF 1 1
