NZXT T120 - Heatsink Mounting

07
T120 & T120RGB
Place the heatsink with the retention bracket onto the
CPU and ensure the bracket screws go into the backplate
holes. Secure the screws in the order as shown.
STEP 5. (INTEL)
Install the four AMD sleeves and then place the heatsink with
the retention bracket. Secure it with the #6-32 screws in the
order as shown.
STEP 5. (AMD)
2. INSTALLATION
1
2
3
4
K
J
