51
If not, the cable pull must be adjusted using the register shown in the figure.
Reverse lever (if available):
Machine movement must begin when the reverse lever overcomes half of its stroke as shown
in the figure.
If not, the cable pull must be adjusted using the register shown in the figure.
Tool engagement lever:
Machine movement must begin when the tool engagement lever exceeds half of the stroke as
shown in the figure
If not, the cable pull must be adjusted using the register shown in the figure.
9.2 Machine oil changes
The oil in the base of the machine mustbe changed every 60 hours or so of work.
Lift the machine as described in the „HANDLING AND TRANSPORT” chapter.
Then proceed as follows:
INFORMATION!
Use a syringe (not included) for easier and safer extraction.
CAUTION!
Use SAE 80 or equivalent oil.
Proceed in reverse order to reassemble the wheel.
9.3 Tyre inflation
We recommend checking tyre inflation before each machine use. The recommended value is
21 PSI (1.5 bar).
