O.S. engine GF40U-FI - Accessories; Igniter; Spark plug; Fuel filter and Non-bubble weight

Accessories
5
【Igniter】 Model:IG-08A
・The red connector is a power connector. Supply DC6V～12.6V
(MAX1A) for operation. The ignitor requires a separate power
source from that of the ECU. Install a power switch outsidfe of a
fuselage between Ignitor and power source for safety.
・
Connect the black connector to Ignition signal cable of ECU
【Spark plug】
・Screw into the engine's cylinder head.
・NGK CM-6 Spark plug.
・the hexagon size is 14mm.
・Tightening torque is 12N・m
【Fuel filter】【Non-bubble weight】
・Inline fuel filter to be used between a fuel tank and a pump. The
arrow mark shows the direction of fuel flow.
・Non-bubble weight to be used in a fuel tank to avoid air bubbles
in fuel line.
【Hose clamp】
・To be used to fix pressurized tubes to joints.
・Recommended tube: EIGHTRON Flexible Fluorine (ETFE) Resin
Tubing Clear made by HAKKO CORPORATION / JAPAN
Code No.28382303 FLUORINE(ETFE) RESIN TUBING (2m)
※
Be sure to use this tube where pressure is applied.
【Connector lock】
・For crankshaft rotation sensor，the power connector of Igniter，
and Ignition signal connector to prevent connectors from
disconnecting.
【Socket wrench (SST)】
・A special tool for attaching and detatching the temperature
sensors. (intake air temperature sensor and cylinder head
temperature sensor)
・Attach this tool to 1/4"(6.3mm) Socket wrench handle. (Socket
wrench handle is not included in this set)
【Serial signal converter】
・To be used to convert UART serial signal from ECU to RS-232C
serial signal when ECU is connected to a computer.
【Power supply code】
・Supply power.
・DC10V～17V(MAX1.5A)
