O.S. engine MAX-21TM User Manual

32
21TM (Revo) ENGINE EXPLODED VIEW
Type of screw C…Cap Screw M…Oval Fillister-Head Screw
F…Flat Head Screw N…Round Head Screw S…Set Screw
＊
C.M3x16
1
2
3
5
4
6
7
8
9
10
11
12
14
13
15
17
M.+M2.6x7
16
33
21TM (Revo) ENGINE PARTS LIST
The specifications are subject to alteration for improvement without notice.
79871160 21914200 21921400 21913300 23906000 21817000 21915000 21982010 25381701 23731000 21921000 21931000 21912000 21922000 21921800 21911800 79860070 71653000 21427200 72103810 72106172
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17
Cylinder Head Retaining Screw (10pcs.) Heatsink Head Head Gasket (1pc.) Cylinder & Piston Assembly Piston Pin Piston Pin Retainer (2pcs.) Connecting Rod Carburetor Complete (Type 11K-R) Carburetor Retainer Crankshaft Ball Bearing (Front) Crankcase Crankshaft Ball Bearing (Rear) Crankshaft Starting Shaft Cover Gasket Rear Adaptor Rear Adaptor Retaining Screw (10pcs.) Glow Plug LC3 Exhaust Seal Ring (2pcs.) Exhaust Manifold M1021 Manifold Spring (2pcs.)
Description
Code No.
No.
