O.S. engine MAX-21TM User Manual

36
11K-R CARBURETOR EXPLODED VIEW
Type of screw
C...Cap Screw M...Oval Fillister-Head Screw
F...Flat Head Screw N...Round Head Screw S...Set Screw
S.M3x3
1
1-1
1-2
2
2-1
2-2
3
4
8
9
10
5
6
6-1
7
3-1
37
The specifications are subject to alteration for improvement without notice.
11K-R CARBURETOR PARTS LIST
1
1-1
1-2
2
2-1
2-2
3
3-1
4
5
6
6-1
7
8
9
10
Description
Code No.
No.
22615000
22781800
27881820
21982700
21982620
27881820
21285901
21982100
21982200
21982540
21982520
23818440
21881950
22781800
Carburetor Rubber Gasket
Throttle Lever
Dust Cover
Metering Needle Assembly
Slide Valve
No.14 Universal Nipple Assembly
Carburetor Body (w/Thermo Insulator)
"O" Ring (2pcs.)
Needle Valve Assembly
Throttle Stop Screw
"O" Ring (S) (2pcs.)
"O" Ring (L) (2pcs.)
Mixture Control Valve Assembly
"O" Ring (S) (2pcs.)
Thermo Insulator
21982900
22781800
"O" Ring (S) (2pcs.)
