O.S. engine MAX-25AX & MAX-35AX User Manual

48
4.07 cc / 0.248 cu.in.
18.0 mm / 0.709 in.
16.0 mm / 0.630 in.
0.7 ps / 0.71 hp / 14,000 r.p.m.
2,500-15,000 r.p.m.
0.8 ps / 0.81 hp / 16,000 r.p.m.
2,500-17,000 r.p.m.
275 g / 9.70 oz.
83.0 g / 2.93 oz
15
19
19
38
33.6
96.2
80.5
18
30.6
45
25
26
76.8
22.5
53
24
99.5
30.5
59.2
UNF1/4-28
35
Displacement
Bore
Stroke
Power output at
recommended R.P.M. range
Recommended R.P.M. range
Power output
Practical R.P.M.
Weight
SPECIFICATIONS
Dimensions(mm)
25AX THREE VIEW DRAWING
(E-3080 Silencer)
49
18
30.6
45
25
26
15
19
19
38
33.6
96.2
22.55324
99.5
30.5 61.5
UNF1/4-28
80.5
35
76.8
Displacement
Bore
Stroke
Power output at
recommended R.P.M. range
Recommended R.P.M. range
Power output
Practical R.P.M.
Weight
SPECIFICATIONS
Dimensions(mm)
35AX THREE VIEW DRAWING
(E-3080 Silencer)
5.77 cc / 0.352 cu.in.
20.2 mm / 0.795 in.
18.0 mm / 0.709 in.
0.9 ps / 0.91 hp / 11,000 r.p.m.
2,500-13,000 r.p.m.
1.3 ps / 1.32 hp / 16,000 r.p.m.
2,500-17,000 r.p.m.
280 g / 9.88 oz.
83.0 g / 2.93 oz
