Device Dimensions
with Handle/Wheels
H: 20.29 in H: 51.5 cm
W: 10.85 in W: 27.55 cm
D: 9.45 in D: 24 cm
Cart Kit (Wheels & Pull Handle)
0.5 to 3 LPM in 0.5 LPM increments; Measured flow
values are within ± 2% of actual values. Max flow 3.0
LPM. Flow maintained with outlet pressure ranging from
0 to 5.0 psig (0-34kPa)
0.5 to 6.0 (8mL-96mL) setting increments; Measured flow
values are within ± 2% of actual values
14.4V Lithium Ion Battery
External Power Supply Power
Input
AC power: 100 - 240 VAC, 50/60 Hz
@ 2.5 amps
DC power: 12-15 VDC; Recommended: 15A outlet at
12V
91% ± 4% (87 - 95%) from 0.5 to 3.0 LPM; Measured purity
values are within ± 2% of actual values; There is no
variation in purity within the operating altitude.
50°F (10°C) to 104°F (40°C)
10% - 95% @ 82.4°F (28°C)
Operating Atmospheric
Pressure
Free of smoke, pollutants, and fumes.
Transport/ Storage Temperature
-4°F (-20°C) to 140°F (60°C)
Transport/ Storage Humidity
24 hours per day when connected to an external AC or
DC power source. This is a continuous operation device.
DO NOT use cannula tubing longer than 7ft (2.13m)
when using Pulse Flow Mode
Do NOT use cannula tubing longer than 50ft (15.25m)
when using Continuous Flow Mode.
A-Weighted Sound Pressure
Level
The volume that the device will reach at maximum
settings will be ~ 56dBA with maximum peaks of
58.8dBA.
All alarms triggered by the device will be 85dBA at
10cm from the unit.
Device will maintain flow up to 5psi back pressure.
Maximum back pressure is 7.0psi.
Device: 5yrs, Accessories: 1yr
