Oaks Smart Access Control System - Wiring and Power Supply; Wiring Scenarios: Magnetic Lock and Electric Strike; Power Supply Controller Specifications

Page 5
(continued)
Wiring Diagram
Installation
Power Supply Controller
Specifications
No. Item Specification
1 Input AC110 V 50Hz
2 Output DC12 50VA
3 Dimension 180mm X78m X 65mm (7in X 3in X 2.5in)
4 Weight 1250g (2.75lb)
5 Ambient Temp -20C°--- 55C° (-4F°---122F°)
6 RH 30%-90%
