Oase ClearTronic 7 W User Manual

‐EN‐
6
1. ChecktheOringattheunitheadforcorrectseating.
– CleantheOring,replaceifdamaged.
2. Carefullypushthe unitheadintothecasingupto
thestopwhileapplyingslightpressure.
– Turntheunitheadslightlysothatthetenonsand
groove
softhebayonetclosureintermesh.
3. Turntheunitheadclockwiseuptothestop.
– Thetwoarrowsonthecasinganduni theadmust
pointtowardsoneanother.
Cleaningthequartzglass/ReplacingtheUVClamp
Replace the UVC lamp after max. 8,000 operating
hours.Thisensuresoptimumfilteringperformance.
Attention! Breakableglass.
Possible consequences: Injury to your hands
causedbycuts.
Protectivemeasures:Handlethequartzglassand
UVClampwithcare.
Prerequisite
 Theunitheadisremoved.(→ Dismantlingtheunit
head)
 Ensurethattheidentificationandcapacitydataof
theUVClampsusedcorrespondtotheinformation
ontheunittypeplate.(→ Technicaldata)
Howtoproceed:
G
1. Loosentheself‐tappingscrewuntilthethescrewtip
issunkinthehous
ingoftheclampingscrew.
2. Unscrewtheclampingscrewcounter‐clockwise.
3. Remove the qua rtz  glass including the O ring to‐
wardsthefrontwithaslightturningmovement.
4. PullouttheUVClampandreplace.
5. Pushthequartz glassincluding theOringasfaras
thestopintheunithead.
– CleantheOring,replaceifdamaged.
– EnsurethattheOringislocatedinthegapbe‐
tweentheunitheadandthequartzglass.
6. Tighten the clamping  screw cl
ockwise up to the
stop.
7. Tightentheself‐tappingscrew.
8. Wipethequartzglasstubewithadampcloth
9. On completion of the work, fit the unit head.
(→ Fittingtheunithead)
WEARPARTS
Thefollowingcomponentsarewearparts:

 UVClamp,quartzglassandOringforquartzglass
DISPOSAL
Do not dispose of this unit with domestic waste! For
disposal purposes, please use the return system pro-
vided. Render the unit unusable beforehand by
cutting the cables.
SPARE PARTS
The use of original parts from OASE ensures
continued safe and reliable operation of the unit.
Please visit our website for spare parts drawings and
spare parts.
http://www.oase-livingwater.com/
spareparts-international-ia
NOTE
Forsafetyreasons,theUVClampcanonlybeswitched
onwhentheunitheadhasbeencorrectlyfittedinto

thecasing.
Howtoproceed:
E
1. Turntheunitheadcounter‐clockwiseuptothestop
andcarefullypullitoutofthecasi ngtogetherwith
theOring.

2. Cleanthecasingfromtheinsideandtheoutside.
Fittingtheunithead
Howtoproceed:
F

MAINTENANCEANDCLEANING
If necessary, cleantheunit with clear waterusing a
softbrush.
 Donotusecleaning agents or chemical solutions.
WerecommendusingOASEPumpCleanforremov‐
ingcalciumdeposits.
Dismantlingtheunithead
CAUTION
The ultra‐violet radiation of the UVC lamp can burn
youreyesandskin.
 NeveroperatetheUVClampoutsideitscasing.
 NeveroperatetheUVClampinacasingthatisde‐
fective.
Attention!Breakableglass.
Possible consequences: Injury to your hands
causedbycuts.
Protectivemeasures:Handlethequartzglassand
UVClampwithcare.
