38
Technical data
Filtoclear 3000 6000 11000
Dimensions in mm (ØxH) Ø 380 x 310 Ø 380 x 430 Ø 380 x 550
Inlet and outlet ¾“ to 1½“ ¾” to 1½“ ¾“ to 1½“
Filter volume in litres 5 9 14
Crystalline filter surface in m² 5.3 10.5 15.8
Integrated UVC clarifier 9 W 11 W 11W
Nominal voltage UVC 230V/50Hz 230V/50Hz 230V/50Hz
Lamp components UVC TUV PL-S 9W TUV PL-S 11W TUV PL-S 11W
Cable length in m 5 5 5
Weight in kg 5 5.5 6
Instruction for use
Wearing parts
Filtoclear 3000: Spare UVC lamp 9W ID No. 54984
Spare filter set Filtoclear 3000 ID No. 56109
Spare set of seals ID No. 34581
Filtoclear 6000: Spare UVC lamp 11W ID No. 56112
Spare filter set Filtoclear 6000 ID No. 56110
Spare set of seals ID No. 34581
Filtoclear 11000 Spare UVC lamp 11W ID No. 56112
Spare filter set Filtoclear 11000 ID No. 56111
Spare set of seals ID No. 34581
