Oasis PCPEBF - Page 7

STEP 1 & 2:
1. Carefully unpack Water Dispenser and remove filter from the alcove
(filtered models only).
2. Remove Front Panel by removing the 2 screws at the bottom of the panel
on the sides. See Diagram 1 and 2.
6. INSTALLATION:
6. INSTALLATION:6. INSTALLATION:
6. INSTALLATION:
7
DIAGRAM 1
DIAGRAM 2
REMOVE
T15 TORX SCREWS
QTY. 2
