STEP 6:
6. Locate the Snap Bushing in the back of the cabinet and feed 1-1/2” OD Drain
Pipe through the hole. See Diagram 4 & 5.
6. INSTALLATION:
6. INSTALLATION:6. INSTALLATION:
6. INSTALLATION:
9
DIAGRAM 4
Front View
DIAGRAM 5
Rear View
P-Trap Located
behind the
filter mounting
bracket
Drain Pipe –
shown after
completing
Step 6.
