OBL PRO Series User Manual

File: UT-5601 Copyright © - OBL Metering pumps - All rights reserved
36
mA
40028
DIP_MIN
W/R
R
2
1
9999
600
(L/h o
Gal/h)*10
Max flowrate analog mA mode
M_FLOW
40029
DIP_MAX
W/R
R
2
0
9999
0
(L/h o
Gal/h)*10
Min flowrate analog mA mode
M_FLOW
40030
DIP_MIN
W/R
R
2
1
10
10
V
High value voltage 0-10 V analog
V mode
40031
DIP_MAX
W/R
R
2
0
10
0
V
Low value voltage 0-10 V analog
V mode
40032
DIP_MIN
W/R
R
2
1
9999
600
(L/h o
Gal/h)*10
Max flowrate analog V mode
M_FLOW
40033
DIP_MAX
W/R
R
2
0
9999
0
(L/h o
Gal/h)*10
Min flowrate analog V mode
M_FLOW
40034
M_U16
W/R
R
2
1
65535
100
PPM
PPM desired in the tank PPM
mode
40035
M_PERC
W/R
R
2
1
100
100
%
Concentration dosed fluid PPM
mode
40036
M_PERC
W/R
R
2
1
100
100
%
Concentration in the tank
percentage mode
40037
M_PERC
W/R
R
2
1
100
100
%
Concentration dosed fluid
percentage mode
40038
M_U16
W/R
R
2
1
1000
100
MLQ
MLQ desired in the tank MLQ
mode
40039
M_PERC
W/R
R
2
1
100
100
%
Concentration dosed fluid MLQ
mode
40040
DIP_MIN
W/R
R
2
2
1000
2
p/m
High value pules p/m pulse mode
M_P_M
40041
DIP_MAX
W/R
R
2
1
1000
1
p/m
Low value pules p/m pulse mode
M_P_M
40042
DIP_MIN
W/R
R
2
1
9999
600
(L/h o
Gal/h)*10
Max flowrate pulse mode
M_FLOW
40043
DIP_MAX
W/R
R
2
0
9999
0
(L/h o
Gal/h)*10
Min flowrate pulse mode
M_FLOW
40044
M_PRESSURE
W/R
R
2
1
300
1
Bar
Calibration pressure – calibration
window
40045
M_TYPE_START
W/R
R
2
0
1
0
Batch start
Value 0=manual
Value 1=external
40046
M_FLOW
W/R
R
2
1
9999
600
(L/h o
Gal/h)*10
Flowrate pause work mode
40047
M_CONTACT
W/R
R
2
0
1
0
Contact output relay
Value 0=NO
Value 1=NC
40048
M_YES_NO
W/R
R
2
0
1
0
Level START contact activation
Value 0=No
Value 1=Yes
40049
M_YES_NO
W/R
R
2
0
1
0
Level STOP contact activation
