10. DISPLAY AND FUNCTION KEYS
11. ASSEMBLING THE E-SCOOTER
- After removing the e-scooter from the packaging and checking that everything is compliant with
what is indicated in paragraph “8”, it is necessary to assemble the dismounted components.
a• Open the kickstand (2) and position the e-scooter on a at surface.
b• Raise the handlebars stem (7).
c• Raise the locking lever (6) and push it against the handlebars stem (7) until a hooking “click”
is heard.
d• Insert the handlebars (9) on the handlebars stem (7).
e• Use the Allen wrench (e) to tighten the screws (d) on both sides. If you notice any vibration
of the handlebars, check the screws of the folding intersection (5); if necessary use the Allen
wrench to lock the two screws. The suggested tightening force for handlebar screws is about
5~8 Nm.
f• Press the ON/OFF button (25) to check that the e-scooter is switched on correctly.
click !
2
7
a
b
c
6
7
d
5
e
25
9
f
103
EN
