MNL-1029 Rev A
6
External Reset Input Pin
The Ocean SR2 can reset itself via an external reset pin. Applying a logic low input to the RSTn pin places the SR2 into a hardware
reset condition and will remain in reset until the input is brought high again. Note that this is a full hardware reset, all operating
parameters are also reset to defaults that can be restored by re-initializing via software commands.
16 Pin Connector Cable (CBL-ISDF-DB15)
This cable connects to the following external light sources:
DH-3P
DH–2000 (US)
HPX–(US)
HL–2000–FSHA
HL–3P
16 Pin Connector Cable (CBL-ISDF-PX-DB15)
PX-2
