EPIRB1 User Manual
912S-01365 v01.22 13 01/06/23
6.5 Specifications
406MHz Transmitter
Frequency 406.040 MHz ±1KHz
Output Power 12W max EIRP
Modulation Phase ±1.1 Radians Pk (16K0G1D)
Encoding Biphase L
Rate 400 bps
121.5MHz Transmitter
Frequency 121.5 MHz
Output Power 40mW±2dB
Modulation Swept Tone AM (3K20A3X)
Modulation Depth ~97%
Frequency Stability ±50ppm
Duty Cycle ~35%
Low Duty Cycle Strobe
Light Type Dual High Intensity LED
Flash Rate 20-30 per minute
Battery
Type Lithium Manganese Dioxide (LiMnO2)
Operating >48Hours @ -20°C
Battery Replacement Period 10 years
GPS Receiver
Satellites Tracked 66 Channel
Sensitivity -148dBm
Cold Start Re-acquisition -163dBm
GPS Antenna Microstrip Patch
NFC Transmitter/Receiver
Operating Frequency 13.56 MHz
General
Dimensions of Body 178mm x 89mm x 100mm
Weight 422grams
Environmental
IEC60945 Category Portable
Temperature Class 2 (Operating -20C to +55C), (Storage Class 2 -30C to +70C)
Waterproof 10m depth
Approvals
Cospas Sarsat standards T.001, T.007
Test standards IEC61097-2, EN 62368-1, EN 302 489, RTCM SC11000-2
Class
Australia/New Zealand Class 3 (Manual activation only)
RoW (except Aus/NZ) Class 2 (Manual and Automatic activation)
