Oceasoft Emerald - Installation and Setup; Inserting the Battery

Inserting the battery into your Emerald module
OCEASOFT Emerald User Guide Page 12
2 Inserting the battery into your Emerald module
Emerald modules feature a replaceable battery.
To get started, you must insert the battery into your module.
The Lithium battery
is provided in the
product box.
Unscrew the three
screws on the back
of the module (turn
counter-clockwise).
Remove the screws.
Place the battery in
the slot, making
sure to respect
polarity.
Replace screws (turning
them clockwise). Ensure
that the rubber seal is
well seated.
Your module is now
ready to use.
Figure 2: Inserting the battery in your Emerald -40°C / +85°C module
1
2
3 4
5
6
