OCULUS BIOM 4 - 15 Technical Data

15 Technical Data
32 / 34 Instruction manual BIOM 4 (G/54400/1011/en)
Image Inverting Systems for BIOM 4
15 Technical Data
Dimensions BIOM 4m and 4c
Dimensions BIOM 4ml and 4cl
Weight
Component Order number
SDI 4c (6-15 V) 54320
SDI 4e (6-15 V) 54300
SDI 4m (mechanical) 54302
Types for Leica-microscopes:
SDI 4c (6-15 V) 54330
SDI 4e (6-15 V) 54310
SDI 4m (mechanical) 54312
Width 63 mm
Depth 111.5 mm
Height 110 - 145 mm
Total height approx. 123-158 mm
Range of safety extension rod approx. 29mm
Width 63 mm
Depth 111.5 mm
Height 124 - 160 mm
Total height approx. 137-173 mm
Range of safety extension rod
approx. 29 mm
BIOM 4m and BIOM 4 c approx. 260 g
BIOM 4ml and BIOM 4cl approx. 265 g
Reduction lens approx. 20 g
Ophthalmoscopy front lens approx. 10 g
