8.ENGINE
8-1
8.ENGINE
ENGINE LUBRICATION CIRCUIT················ 8-1
COOLING SYSTEM WATER PUMP....................8-13
MAGNETO AND STARTER························· 8-24
TOP END SERVICE TOOLS.................................8-32
TIMING CHAIN········································ 8-60
BOTTOM END ENGINE DRIVE SHAFT.........8-69
CONTINUOUSLY VARIABLETRANSMISSION (CVT)..8-89
GEARBOX COUPLING UNIT...........................8-93
ENGINE LUBRICATION CIRCUIT
1. Camshaft bearings
2. Oil pressure switch
3. Oil filter
4. Oil pressure regulator valve
5. Oil strainer
6. Oil pump
7. Crankshaft main bearings
8. Crankshaft support bearing
9. Connecting rod' bearings
