8.ENGINE
8-12
Reed Valve Removal
Remove:
-PTO cover (refer to PTO COVER in the
BOTTOM END subsection)
- Reed valve retaining screws
- Stopper plate
- Reed valve.
Inspecting the Reed Valve
Check reed valve for cracks or other
damage.
Replace reed valve if damaged.
Inspecting the Reed Valve
The installation is the reverse of the
removal procedure.
TIGHRENING TORQUE
Reed valve reating
screws
10N·m±1N·m
