Make sure the valve is flexible and not
inverted, damaged or plugged.Installing
the Air Filter Insert the filter carefully. Seat
the filter by hand, making certain it is
inserted completely into the air cleaner
housing. Apply pressure by hand at the
outer rim of the filter, not the flexible
center.Secure air filter cover with latches.
EXHAUST SYSTEM
Cleaning and Inspecting the Muffler Spark
Arrester
CAUTION: Never perform this operation
immediately after the engine has been
running as exhaust system is very hot.
Remove and discard tail pipe fasteners.
Remove exhaust tail pipe, gasket (discard)
and spark arrestor.
Remove carbon deposits from the spark
arrester using a brush.
NOTICE: Use a metallic soft brush and be
careful to avoid damaging spark arrestor
mesh.
LUBRICATION SYSTEM
Verifying the Engine Oil Level
NOTICE Operating the engine with an
improper level may severely damage
engine. With vehicle on a level surface and
engine cold, check the oil level as follows:
1. Open cargo box.
2. Remove dipstick and wipe it clean.
RH SIDE OF ENGINE
1. Dipstick
3. Reinstall dipstick, screw in it completely.
4. Remove dipstick and check oil level. It
should be near or equal to the upper mark.
TYPICAL
1.Full
2.Add
3.Operating range
