CAUTION: Never use the retaining ring a
second time. Always install a new one.
After installation, water pump shaft with
rotary seal must rotate freely.
Carefully push in water pump gear while
turning to mesh with the inner drive gear.
1.Water pump gear
2.Inner drive gear
Tighten Screws of the water pump housing
crosswise.
Refill all fluids.
