1.Rotate the fan control switch
2.A/C switch
3.Rotating the temperature control switch
Rotate the fan control
To operate the cab heater, rotate the fan
control 1 to the desired fan speed setting.
The far left setting turns the fan off.
Rotary temperature control
Adjust the temperature by rotating the
temperature control 2 to the desired heat
setting. Rotate the control clockwise to
increase heat or counterclockwise to
decrease heat.
A/C switch
Press the top of the A/C switch 3 to enable
the air conditioning system for cooling or
defrost purposes.
HVAC FILTER INSPECTION / REPLACEMENT
1.If you feel that the wind speed of the air
conditioner has significantly decreased or
the cooling effect has significantly
decreased, please open the maintenance
window of the air conditioning system in
the car and perform a deep cleaning of the
cooler.
2. Remove the hood and the cabin air filter
3. Clean the filter with low air pressure.
Check for damage, replace if damaged.
The basic components of HVAC
system are:
AC system, heating system, air supply
system
AC SYSTEM
AC system consists of: compressor,
condenser, evaporator, TXV, blower, pipe,
electrical components.
