6.ELECTRICAL SYSTEM
6-14
Z If the voltage is lower than the standard value, replace coupling coil.
Resistance of coupling coil
The multi meter is put at 1x100Ω step.
Resistance of coupling coil: 135±5Ω
Z If the resistance is not within the specified value, replace the coupling coil.
Inspecting an Electrical Connection
When replacing an electric or electronic component, always check electrical connections.
Make sure they are tight, make good contact, and are corrosion-free.
Dirty, loose or corroded contacts are poor conductors and are often the source of a system
or component malfunction.
Pay particular attention to ensure that pins are not bent or pushed out of their connectors.
Ensure all wire terminals are properly crimped on wires, and connector housings are
properly fastened.
