http:// www.odotautomation.com 8 / 15 TEL: +86-0816-2538289
2.2 Product identification drawing
Take ODOT-MS116T as example（ODOT-MS105T,ODOT-MS108T is similar）
2.3 Wiring diagram
Table 2.3.1 ODOT-MS105T wiring instruction
Wiring port
Wiring marking
Wiring instruction
1
PE
Earthing
2
V-
Power input negative
3
V+
Power input positive
