odot ODOT-MS105T User Manual

http:// www.odotautomation.com 9 / 15 TEL: +86-0816-2538289
Table 2.3.2 ODOT-MS108T wiring instruction
Wiring port
Wiring marking
Wiring instruction
1
PE
Earthing
2
V-
Power input negative
3
V+
Power input positive
Table 2.3.3 ODOT-MS116T wiring instruction
Wiring port
Wiring marking
Wiring instruction
1
PE
Earthing
2
V2-
Power 2 input negative
3
V2+
Power 2 input positive
4
PE
Earthing
5
V1-
Power 1 input negative
6
V1+
Power 1 input positive
2.4 LED indicator description
1. Power LED
Table 2.4.1 ODOT-MS105T/108T LED instruction
Marking
Status
Definition
PWR
ON (RED)
Power supply is normal
OFF(RED)
Power supply is abnormal
Table 2.4.2 ODOT-MS116T LED instruction
Marking
Status
Definition
PWR1
ON (RED)
Power supply 1 is normal
OFF(RED)
Power supply 1 is
abnormal
