Odyssey PC680 - Page 4

0.73”
(18.5 mm)
A
B
SAE TERMINALS
34-790
34R-790
48-720
65-760
75/86-705
TERMINAL
0.682” 0.759“
(17.3 mm) (19.3 mm)
0.619” 0.696”
(15.7 mm) (17.7 mm)
POSITIVE
NEGATIVE
DIM A DIM B
TERMINAL
0.682” 0.759“
(17.3 mm) (19.3 mm)
0.619” 0.696”
(15.7 mm) (17.7 mm)
POSITIVE
NEGATIVE
DIM A DIM B
B
A
0.68”
(17.3 mm)
0.13” (3.2 mm)
SAE TERMINAL
31-800T
A
B
0.20”
(5.1 mm)
0.59”
(15.0 mm)
0.85”
(21.6 mm)
0.73”
(18.6 mm)
TERMINAL
0.682” 0.759“
(17.3 mm) (19.3 mm)
0.619” 0.696”
(15.7 mm) (17.7 mm)
POSITIVE
NEGATIVE
DIM A DIM B
THREAD
3/8-16
5/16-18
THREAD
MARINE (DUAL TERMINAL)
31M-800
34M-790
3/8-16 THREAD
0.34” DEEP
0.85”
(21.6 mm)
1.12”
(28.5 mm)
SIDE TERMINALS
78-790
75/86-705
0.63” - 0.67”
(16 mm - 17 mm)
0.85”
(21.6 mm)
0.19”
(4.7 mm)
STUD TERMINALS
31-800S
NEGATIVE POSITIVE
B
B
0.732”
(18.6mm)
A
A
TERMINAL
0.677” 0.759“
(17.2 mm) (19.3 mm)
0.614” 0.696”
(15.6 mm) (17.7 mm)
POSITIVE
NEGATIVE
DIM A DIM B
75/86-PC1230 25-PC1400 35-PC1400
34-PC1500 34R-PC1500 34/78-PC1500
65-PC1750 31-PC2150T
SAE TERMINALS
.65”-.75”
(16.5-19.1mm)
3/8-16 THREAD
31-PC2150S
M6 FEMALE
THREAD
PC535 PC625
0.43”
(11.0 mm)
M6 THREAD
PC370 PC950 PC1100
M6 FEMALE
THREAD
ALL OTHER MODELS
1.00”
(25.4 mm)
0.53”
(13.5 mm)
3/8-16
THREAD
PC1800-FT
(FRONT TERMINAL)
3/8-16 THREAD
0.34” DEEP
0.85”
(21.6 mm)
1.12”
(28.5 mm)
75-PC1230 75/86-PC1230
78-PC1500 34/78-PC1500
SIDE TERMINAL
0.669”
(17.0 mm)
0.039”
(1.0 mm)
A
A
B B
POSITIVE NEGATIVE
TERMINAL
0.689” 0.768“
(17.5 mm) (19.5 mm)
0.630” 0.705”
(16.0 mm) (17.9 mm)
POSITIVE
NEGATIVE
DIM A DIM B
PC1350
DIN TERMINALS
DIN TERMINAL
3/8-16 THREAD
0.72”
(18.2 mm)
0.96”
(24.5 mm)
PC2250
POSITIVE
SAE
NEGATIVE
SAE
NEGATIVE MARINE
5/16-18 THREAD
POSITIVE MARINE
3/8-16 THREAD
0.568”
(14.4 mm)
34M-PC1500 31M-PC2150
(SEE SAE DIAGRAM
FOR TERMINAL
DETAILS)
BRASS SAE
TERMINAL
(SEE SAE
DIAGRAM FOR
DETAILS)
3/8-16 FEMALE
THREAD
BATTERY
TERMINAL
(FEMALE M6)
OPTIONAL SAE TERMINAL
(INSTALLED ON FEMALE M6 TERMINALS)
4
ODYSSEY
®
EXTREME SERIES
™
BATTERIES
ODYSSEY
®
PERFORMANCE SERIES
™
BATTERIES
Publication No. 2602-0232, Rev AA - September 2016 www.odysseybattery.com
