OEM Tools 24790 - Detailed Parts List

7
Operating Instructions and Parts Manual 24790
5/20
2020 OEMTOOLS
®
1,100 LB. 2 STAGE TELESCOPING
TRANSMISSION JACK
Figure Description Qty.
01 Dust Ring 1
02 O Ring 1
03 Seal Ring 1
04 Saddle 1
05 2nd Stage Ram 1
06 Grease Fitting 1
07 Retainer Ring 1
08 Dust Ring 1
09 O Ring 1
10 Seal Ring 1
11 Ram Nut 1
12 O Ring 1
13 1st Stage Ram 1
14 Retainer Ring 1
15 End Cap 1
16 Screw 1
17 Steel Ball 1
18 O Ring 1
19 Nut Seat 1
20 Seal Ring 2
21 Oil Barrel 1
22 Pin 1
23 Pin 3
24 Handle 1
25 Handle Grip 1
26 Vent Screw 1
27 Seal Ring 1
28 Cylinder 1
29 Seal Ring 1
30 Pump 1
31 Limit 1
Figure Description Qty.
32 Lock Washer 1
33 Screw 1
34 Release Pedal 1
35 Pin 1
36 Pin 1
37 Flat Washer 2
38 Pump Pedal 1
39 Retainer Ring 4
40 Linkage 2
41 Pin 2
42 Pin 1
43 Base 2
44 Nut 4
45 Flat Washer 4
46 Lock Washer 4
47 Locking Castor 2
48 Flat Washer 4
49 Lock Washer 4
50 Bolt 4
51 Screw 2
52 Wheel 2
53 Washer 1
54 O Ring 1
55 Steel Ball 1
56 Spring 1
57 Valve Seat 1
58 Bar 1
59 Spring 1
60 Valve Core 1
61 Filter 1
62 Retainer Ring 1
PARTS LIST
NOTE: Not all components of the Transmission Jack
are replacement reference for location and posting in
the assembly sequence.
