To be read completely before initial start-up!
Operating Manual
E 500-17
von Oertzen GmbH • Ferdinand-Harten-Str. 10 • 22949 Ammersbek • Tel. +49 40 604110 • Fax +49 40 6041149
www.oertzen-gmbh.de • info@oertzen-gmbh.de
9/08

Table of Contents

Questions and Answers

  • K
    Kimberly WallerAug 1, 2025
    Why Oertzen E 500-17 motor does not start?
    • J
      jonterryAug 1, 2025
      The motor may not start due to several reasons: * The motor protection switch might not be pressed. If this is the case, press the motor protection switch. * The machine might not be properly connected to a power source. Ensure the plug is correctly inserted into the socket and the main switch is activated. * A fuse might be burnt. Replace the fuse, but if it burns again, contact a qualified service technician. * A phase might be missing in the plug. Mount the phase according to the electric wiring diagram. * There may be a faulty motor protection switch, in which case you should call a qualified service. * If you have an SCS system installed, there may be an insufficient water supply. Ensure a sufficient water supply.
  • T
    Taylor FrazierAug 7, 2025
    What to do if Oertzen E 500-17 Pressure Washer operating pressure is not achieved or varies?
    • K
      Kristin WallAug 7, 2025
      If the operating pressure is not being achieved or is varying, it could be due to: * Air in the unit. Bleed the unit by opening the pressure regulating handle and pistol until continuous pressure is achieved. * Poor water supply. Ensure the water supply hose is of adequate diameter (refer to the table for specifications). * A worn nozzle. Replace the nozzle. * An incorrect nozzle. Install the correct nozzle. * A clogged nozzle. Remove and clean the nozzle. * A dirty water filter. Clean the water filter. * A leaking suction side. Tighten the hose clamps on the suction hose. * Dirty or sticking suction valves. Remove and clean the valves.
  • C
    Crystal CuevasAug 12, 2025
    Why does Oertzen E 500-17 motor suddenly trip and the motor protection switch stops the machine?
    • M
      Mary Snyder DVMAug 13, 2025
      The motor tripping and the motor protection switch stopping the machine can occur due to: * Poor water supply. Eliminate the cause and restart the machine. * A burnt fuse (or missing phase). Replace the fuse. If it burns again, or the motor makes noise, call qualified service. * Low voltage. Make sure the voltage is correct. * High operating pressure. Clean or replace the nozzle (see Technical Data).
  • B
    Brad MendozaAug 19, 2025
    What causes Oertzen Pressure Washer high pressure hose and pistol to vibrate?
    • E
      Elizabeth YoungAug 19, 2025
      Vibration in the high-pressure hose and pistol is caused by air in the unit. To resolve this, bleed the unit by opening the pressure regulating handle and pistol until continuous pressure is achieved. Also, clean the water filter.
  • K
    Kathryn WellsAug 26, 2025
    Why Oertzen Pressure Washer motor gives noise?
    • C
      Carmen BrennanAug 26, 2025
      If the motor is making noise, it could be due to: * A burnt fuse (or missing phase). Replace the fuse. If it burns again, call qualified service. * A malfunction in the electric network. Check the phases in the plug.

Summary

Introduction and Safety Symbols

Safety Symbols Explanation

Explains symbols for personal safety and operational rules.

Safety Instructions and Precautions

General Operational Safety Rules

Crucial rules for handling, water jet, pressure, hoses, pistols, and environment.

Electrical Safety and Power Connections

Safe electrical connections, power cables, extension cords, and protection devices.

Machine Securing, Repair, and Part Usage

Securing machine, repair safety, and using approved parts for warranty.

Machine Design and Components

Component Functions and System Operation

Explains the main components and their functions in the cleaning system.

Component Identification Diagram

Identifies key parts of the machine via a numbered diagram.

Start-up, Operation, and Shut-down

Pre-Start-up Checks and Water Supply

Essential checks before starting, including water supply requirements.

Power Supply and Hose Connections

Details correct power supply and hose connections for operation.

Operating Procedure and Pipe Cleaning Option

Step-by-step guide for starting, operating, and pipe cleaning.

After Work Procedure and Storage

Steps for safe shutdown, storage, and frost protection.

Maintenance and Care Guidelines

Pump Maintenance and Oil Procedures

Pump oil change intervals, type, and level check procedures.

Filter Maintenance and Frost Protection

Maintenance of micro filter and essential frost protection procedures.

Technical Data and Diagrams

Electric Wiring Diagram

Presents the electrical wiring diagram for the machine.

Machine Technical Specifications

Provides detailed technical specifications for the E 500-17 model.

Trouble Shooting and Repair

Repair Safety and Troubleshooting Guide

Safety for repairs and troubleshooting common malfunctions with causes/solutions.

Declaration of Conformity

Conformity Statement and Product Details

Official declaration of product conformity with EU standards and company details.
