Ofna Racing LD3 - Page 8

Step 1
Step 2
ASSEMBLY OF THE REAL GEAR BOX
(Build a gear box for real)
94004
M 3x12mm
94004
M 3x12mm
94050
M2.6x10mm
94050
M2.6x10mm
94050
M2.6x10mm
Screw
Screw
Screw
Screw
Screw
Screw
5x11x4mm
Ball Bearing
Gear box
Gear box
DIFFERENTIAL
ASSEMBLY
* Add Gear Grease before
closing gear case.
38254
38254
37430
38251
38251
12x15x0.25mm
12x15x0.25mm
Shim
Shim
*Adjust the backlash
with the shim.
*Use 2 pcs in this side.
ASSEMBLY OF THE BRAKE AND DIFF.MOUNT
ASSEMBLY OF THE BRAKE AND 2-SPEED
94004
M3x12mm
Screw
94005
M3x16mm
94005
M3x16mm
Screw
Screw
M3x12mm
Screw
94049
M2.6x8mm
Screw
M2.6x8mm
Screw
Spring
40044
38271
38271
38289
38289
38273
38289
38289
40044
38272
38272
*Take off the double sided tape
before assembly.
Brake Pad
Brake Pad
Brake Pad
Linings
Brake Pad
Linings
1
1
2
2
Bulk Head
cover
Plastic Bushing
Brake Cam
Blake Pad
Spring
Brake Mount/Upper
Brake Mount/Lower
Note: Cam will fit in one
direction. Check step.2
on page 9. Note plastic
stop tab on backside.
Note: Do not over tighten screws
