OHIOSTEEL 4222V2 - Assembly Instructions; Attach Height Adjustment Handle; Insert Bottom Frame Tubes

Shown Installed:
Insert Bottom Frame Tubes (39) into Center Frame Tube (41) and snap into position.
(Note that snap buttons are oriented up)
15
R
DETAIL R
SCALE 1 : 5
39
39
41
DETAIL S
SCALE 1 : 2
Snap Button
UP
51
First remove factory hand tightened nuts from studs. Use nuts to attach Height Adjustment
Handle (15) Using a 9/16" Open End Box Wrench.
5
Assembly Instructions
