Install hardware through front two holes of Long Hitch Tubes as shown.
Hold Adjustment Lever in position and install third bolt as shown.
Pin Adjustment Lever to Handle.
DO NOT TIGHTEN
AT THIS TIME.
Install Clevis Bars as shown; Clevis bolts pass between Hitch Tube bolts.
Tighten Hitch Tube hardware first, then tighten Clevis hardware.
Insert Bottom Frame Tubes into Rear Frame Tube and snap into position.
