39
45
50
38
5038
42
44
42
Slide Hopper Bar into pocket of Hopper Bag as shown.
Place bottom frame assembly into Hopper Bag.
Install Clevis Pins through Hopper Bag, Hopper Bar, and Bottom Frame Tubes
and secure with Hairpins.
Insert Top Frame Tubes into Rear Frame Tube and snap into position.
5
Assembly Instructions
7
9
8
