Ohlins RXF34 - 50-Hour Service Procedures; Pre-Service Notes and Initial Disassembly

3
RXF34/RXF36 50-HOUR SERVICE
Front Fork RXF34/RXF36 50-Hour Service
1
Note! 1
Record the rebound adjuster setting and the pressure in the positive air chamber
and ramp up chamber before service. We recommend using a bike stand to clamp
the steering tube when working on the fork.
1. Thoroughly clean the outside of the fork from dirt or grit.
2. Use a 14 mm wrench to hold the rebound adjuster knob steady.
With a 2.5 mm hex wrench remove the screw and the knob.
2
